Automatic Induction Door Personal Modular Clean Room

Automatic Induction Door Personal Modular Clean Room

    • Automatic Induction Door Personal Modular Clean Room
    • Automatic Induction Door Personal Modular Clean Room
  • Automatic Induction Door Personal Modular Clean Room

    Product Details:

    Place of Origin: China
    Brand Name: OEM
    Certification: CE/ISO9001/ROHS

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: Negotiation
    Packaging Details: Polywood packing
    Delivery Time: 7-15 Working days
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 200 Sets per Month
    Contact Now
    Detailed Product Description
    Name: Air Shower Room Blowing: Automatic Induction Blowing
    Material: SUS304/ SUS 201/ SUS 316/ Powder Coated Steel Application: Clean Room Entrance
    Level Of Noise: <65 DB Energy Source: Electricity
    High Light:

    Personal Modular Clean Room Modular Clean Room

    ,

    1200x1000x2180mm Air Shower Unit

    ,

    Intelligent Stainless Steel Air Shower

    Automatic Induction Door Personal Modular Clean Room





    Description



      When people and goods enter the clean area, they need to be blown through the air shower. The clean air blown out can remove the dust carried by people and goods, and can effectively block or reduce the dust source from entering the clean area. The front and rear doors of the air shower/ cargo shower are electronically interlocked and act as air locks to prevent unpurified air from entering the clean area.



    Feature



    The intelligent voice air shower room has a voice prompt system. During the blowing, the automatic voice system prompts people to complete the entire dusting and dust removal process in an orderly manner, achieving an effective purification effect, and the clean air flow filtered by the high efficiency filter is rotatable. The nozzle is sprayed from all directions to the body to effectively and quickly remove dust particles, and the removed dust particles are filtered by the primary and high-efficiency filters and recycled to the air shower area.





    Parameter:



    Stainless Steel Air Shower

    External size

    ( W * D * H ) mm

    1200x1000x2180

    Internal size

    ( W * D * H ) mm

    800x930x1910
    Personal per cycle 1 - 2 persons
    Air Shower Duration Factory set at 15 seconds ( adjustable )
    Construction Stainless Steel 304 / 201 or Steel With Power Coated
    Fan Consumption 750W * 1set
    Fan Air Flow 1300m3 / h
    Fan Run 2800r / min
    SUS Nozzle 12pcs
    Wind Speed ( m / s ) 22 - 27m / s
    Noise Level 〈 65dB
    LED 20W * 1
    HEPA Filter Size 630x630x6mm
    Efficiency 99.99 % @ 0.3um
    Resistance 〈 220pa
    Pre - Filter Size 785x385x2mm
    Efficiency 75 % @ 5um
    Resistance 〈 30Pa
    Electrical Power 380V / 50HZ
    Quality guarantee 12 months
